The components of the Meoplant implant system are only given to system part Torque [Ncm]
dentists/MCG and dental laboratories or on their behalf. This is to (superstructures / secondary parts)
ensure that the specific knowledge that enables safe application is
available. Meoplant® straight & angled / angled
Meoplant® one-piece solid / ball / bar system
Inhomogeneities can be visually observed on the surface of the im- 30
plant. Complete wetting of the surface is ensured microscopically. MeoLock® one-piece & two-piece
*
Any inhomogeneities that occur therefore have no impact on prod- Perform / Cerec Adhesive Base
uct quality, clinical safety and clinical effectiveness. MeoMulti® straight & angled / angled
Only the tools of Meoplant Medical GmbH may be used for the in- adhesive base 27
sertion. A torque wrench is available for this purpose. This can be MeoLock® Cap
equipped with all the necessary tools via the ratchet adapter. If you MeoMulti® structure (titanium)
are working with a contra-angle that has an ISO shank, the tools
can also be used with these contra-angles. The use of non-system Figure 7: Recommended implant diameters MeoMulti® safety cap 25
components and instruments can impair the function and safety of in relation to tooth position MeoMini® one-piece & two-piece / ball head
the Meoplant implant system. If non-system components are PEEK & PEKK (High Performance Thermoplastics) 15
used, no guarantee and no replacement will be provided. Before the intervention
Impression posts / POM abutments 5-10
Drills, instruments and system components are designed for spe- Before the surgical implantation, a careful patient history and, if Screw plug / cover screw
cific implants and implant diameters . The different diameters are necessary, a third-party history must be taken by the family doctor Gingiva formers / healing caps 2-4
identified by color markings (see Tables 1 and 2 and Figure 7). Use to clarify whether
for other implants or other diameters may result in mechanical fail- e) a more difficult implantation due to the anatomical sit- After inserting the implant, the surgeon's assessment of bone qual-
ure of system components, tissue damage, or unsatisfactory es- ity and primary stability determines when the implant can be
thetic outcomes. uation, loaded. Inadequate quantity and/or quality of available bone, in-
f) a serious surgical problem or general risk,
Table 2: Coding of the MeoClassic implant system g) impaired wound healing and/or osseointegration, or fections and systemic diseases are among the possible reasons for
h) deterioration in proper hygiene and/or care of the im- a lack of osseointegration, both immediately after the procedure
implant Ø [mm] length [mm] colour and after an initial osseointegration.
plant, abutment and prosthesis could occur.
MeoMini® 2.9 8 / 10 / 12.5 White During the procedure If the implant or a screw-in head fractures during insertion due to
MeoClassic® 3.5 8 / 10 / 12.5 / 15 yellow excessive stress on the material, both can be removed again using
All instruments and equipment used during the procedure must be
MeoClassic® 3.8 8 / 10 / 12.5 / 15 red the rescue tool. To do this, attach the rescue tool of the appropri-
in good condition and care must be taken to ensure that the in-
MeoClassic® 4.2 8 / 10 / 12.5 / 15 green struments do not damage the implants or other components. ate size and remove the implant and the screw-in head with a left-
turning movement.
MeoClassic® 4.8 8 / 10 / 12.5 / 15 blue
Due to the small size, choking and aspiration of a component of
MeoClassic® 6.0 8/10 black the Meoplant implant system can occur. Aspiration can lead to After the procedure
shortness of breath and, in the worst case, to asphyxiation. For this To ensure optimal long-term treatment outcome, regular compre-
Table 2: Coding of the MeoTulip (Tissue) implant system
reason, the products must be secured against swallowing and as- hensive follow-up appointments should be scheduled with the pa-
implant Ø [mm] length [mm] colour piration with a thread or dental floss when used intraorally. tient and the patient should be informed about optimal oral hy-
MeoTulip® 3.5 8 / 10 / 12.5 yellow It is essential to follow the drilling sequence while preparing the giene.
MeoTulip® 3.8 8 / 10 / 12.5 red implant bed. The recommended torques are described in Table 3. SURGICAL PROCEDURE
MeoTulip® 4.2 8 / 10 / 12.5 green Table 3: Recommended torques of the superstructures / Care must be taken during all steps not to compromise the sterility
secondary components
MeoTulip® 4.8 6 / 8 / 10 / 12.5 blue of the product and the sterile or sterilized product components.
MeoTulip® 6.0 6 / 8 / 10 black Every implantation is a surgical procedure that requires education,
planning, sterile precautions and gentle treatment of the soft and
hard tissues. This includes drilling with sufficient cooling and with
